cabinet minister（mm）
|
8500
|
Hair move machine parameter
|
engine type
|
YC4G180-50
|
|
|
total width（mm）
|
2480
|
|
engine type
|
engine type
|
|
|
overall height（mm）
|
3435
|
|
Engine position / fuel oil
|
Rear / diesel
|
|
wheel base（mm）
|
4000
|
|
Engine type
|
orthostichous
|
|
Front suspension / rear suspension（mm）
|
1800/2700
|
|
Maximum net power (kw / r/min)
|
132KW
|
|
|
Approaching angle / departure angle（°）
|
10/9
|
|
Maximum torque (N.m / r/min)
|
660N.m/1100～1600r/min
|
|
|
Front / rear wheel distance（mm）
|
1930/1800
|
|
output volume（L）
|
5.2
|
|
|
manufacturer's maxumum total mass（kg）
|
12000
|
|
Cylindion trip（mm）
|
112
|
132
|
|
Rated Members (person)
|
70/10-35
|
|
effluent standard
|
country V
|
|
Top vehicle speed (km/h)
|
69
|
|
|
|
hanger bracket
|
Plate spring suspension, front 9 rear 11
|
|
|
turn
|
steering wheelφ450
|
|
|
braking
|
Air brake, self-adjusting arm, break the air brake; ABS Komi
|
|
|
fuel tank
|
120L
|
|
|
tyre
|
8.25-20,
|
8.25R20
|
|
dynamotor
|
28V120A
|
|
|
storage battery
|
DC24V150Ah
|
|
|
bodywork
|
Half bearing
|
|
|
Door and door pump
|
Two passenger doors, the pneumatic folding door
|
|
|
bin gate
|
2 side compartment, backup luggage compartment
|
|
|
Windshield, side window
|
Inside push and pull type, glass color F green, sky blue curtain
|
|
|
Rear view system
|
Manual rearview mirror
|
|
|
Air conditioning / ventilation window
|
Non-independent overhead air conditioner 20000 kcal,
|
|
|
Warm wind / defrosting
|
Heater 3 sets / front gear defroster
|
|
|
audiovisual system
|
Radio, reversing image
|
|
|
lamps and lanterns
|
Overall front and rear headlights, 3 ceiling ceiling lights, 8 side sign lights, rear taillights, license plate lights, step lights, profile lights
|
|
|
rain wiper
|
convention
|
|
|
seat
|
Plastic bus seat, gray, 2 + 1 layout
|
|
|
bar
|
Both side handrails, side fence
|
|
|
plastic flooring
|
Quartz sand floor leather
|
|
